Post Re: FINALLY got me a Thing!
Oh wow, I'm way behind here!

Let's talk about getting the gas heater working shall we?

I had several problems to start off with - one was that my timer switch had no "timer" to it... it just operated like an on/off switch with no winding action..
the other was that inside my thermostat, the little lever bit would not turn and it was stuck at min temp setting.

Also the fuel pump/solenoid thingy was stuck. Fuel pump failure was solved with lots of PB and a few strategic hammer blows, and she was freed up.


I bought a new timer switch from TTS (an early Christmas present to myself) and installed.

The heater pipe seal ring is a 211 part # according to TTS parts guide, but couldn't find it locally. Scrounged and found that a fuel-injected bug tail pipe seal ring does the job.

Heater ignites, runs, gets up to temp. The shutdown after-burn operates properly, and after cooling it starts back up again. This is on the lowest setting though due to my jammed up thermostat.. but it proves operation. I have a parts heater on the way from a friend to cannibalize for parts if needed.


My only apparent issue now is a bit of an uneven flame .. the sound is rumbly from the exhaust rather than a nice even roar. Funny thing is, that it was nice and even when I had it all rigged up top. Only after I had the fuel pump and lines run from below did it start with uneven ignition.

Not sure where to start there, I had already cleaned up and adjusted my spark/glow plug.. maybe i'll swap for the one in the spare unit when it arrives and see what happens.





Since I never found anywhere, anything that describes the internal workings of the BN4 thermostat, I thought I would document everything as best I could.

Here we go:

Inside the thermostat unit, there is the lever which is attached to your temp-adjustment cable. This lever operates on an "outer" barrel with a threaded top and flats. This barrel shaft runs through the thermostat housing, and on the bottom side one end of the bi-metal coil is screwed to it.
Through this barrel, a stainless shaft runs through the centerline. On top inside the thermostat housing the little white plastic cam which operates the switch is pressed onto it. On the bottom end outside the housing, the bottom of the bi-metal coil attaches to the rod via a rivet.

When you actuate the temp cable, you're actually twisting on this OUTER barrel, which pre-winds the bi-metal coil a bit, pulling the cam farther away from the switch.

Let's look at a pic:


The problem I had with both of my thermostats (and perhaps many others) was that the outer barrel part was seized to the thermostat housing. The spare thermostat was stuck so hard someone had bent the lever pulling on the cable so hard.

The problem is finding a way to get on that outer barrel part without destroying everything around it. On the bottom end of the thermostat (the part that goes down into the duct) there's a cage thing around it, and I never did find a way to remove it without possible damage to the bi-metal coil.


Not finding any real function to the cage, I just cut the damned thing off:


Now you have some room to work, maybe even bust the barrel free - which I actually did, but it was still rough. You'll need to remove everything and give it all some proper lubrication.

To get the inner shaft out, go back up top. You'll need to remove the white plastic cam, but first make an index mark so you know how to fit it back w/out losing the factory adjustment:


After removing the small slotted screw that affixes the top of the bi-metal spring to the barrel, the shaft and bi-metal coil should slide out.


Next you can *CAREFULLY* get on the brass nut and lock washer, and remove the actuating lever and plastic do-dad under it. You're left with the empty thermostat housing:


Here's a pic of the sacrificial lamb unit, with components laid out in assembly order:


*CAUTION*
You'll notice an extra "nubbin" lying at the end of the shaft.. that's the threaded tip that broke off trying to losen it up with twisting action. DO NOT TWIST!! DO NOT EVEN TRY TOUCHING THE THREADED TOP!!
The threads are brass and will strip/break off if you so much as look at them cross-eyed!!!

Here's a crop of the barrel, inner shaft and bi-metal coil, you can easily see how it all goes together here:


You'll want to clean up all the burnishing on the barrel bit, for this I used the finest emery cloth I could find and gave it a polish:


Now, for re-assembly and lube.... hmm lube... what do I have handy...
AHA! Gun grease! and CLP! If it's good enough to lube up cosmoline-frozen Mosin-Nagant bolts it's plenty good for a Eberspacher! Made just for extreme-temp variances, and a little bit goes a very long way.
Also, it was within reach:


Installation is the reverse of assembly, as they say. Be sure to get the plastic cam back on the right spot, and that it all moves freely.

Re-install in the car and adjust cable as per the manual.

Enjoy your crankin' hot heat! Now witness the power of this fully operational battl... er, Thing Gas heater!
